See below for lists of applications, firmware, and software use instructions. Jump to:
See below for lists of applications, firmware, and software use instructions. Jump to:
SOFTWARE APPLICATIONS
xtremeDB-Block-Tool-3.5.0.0
PC application used to configure xtremeDB blocks to allow the operator to test and evaluate settings. Produces configurations in both decimal and hexadecimal. Can be used with or without the programming kit, now has PCAN compatibility. See the Quickstart Guides for more information.
DPNPlayer_2.2.2.3
PC tool that interfaces with either PCAN or the Data Panel 30009-1 Universal CAN Gateway (UCG) via USB to parse DPN and SPN into readable numbers and display messages from a CANBUS network. See the Quickstart Guide for more information.
DPLogic2-3.5.1.0
PC tool used to create a PLC ladder logic program to configure any Data Panel DPLogic2 device to perform functions as a controller. Requires the Data Panel Programming Kit.
See the DPLogic2 User Manual for more information.
DPLoader_4.0.0.1
PC tool that interfaces with Universal CAN Gateway via USB and PCAN to perform program updates to the firmware of a Data Panel module. In the case of xtremeDB, the programming kit is required. See the Quickstart Guide for more information.
FIRMWARE
DPN FILES
EDS FILES (CANopen)
SEE THIS MESSAGE AFTER DOWNLOADING?
You're seeing this pop-up because the application was downloaded from an internet source.
We assure you, this application was safely designed and updated by our in-house software engineering team to specifically and only service your devices.
To remedy the security block pop-up, before trying to open the file, right click the file and select the Properties option, which will allow you to disable the security feature for this file.
Likewise, if you would like to use the updated programs, especially with the PCAN feature, please note the following:
Peak System – PCAN-USB
If downloading PCAN software for the first time, download both the PCAN Device Driver for Windows and the PCAN-Basic API. Unblock the driver and the PCAN-Basic API files, then run the driver and allow it to install on your device. When this is finished, launching the Data Panel application will be successful.
